»320selectable UHF frequencies and True Diversity reception for interference-resistant operation.
»THe transmitters offer durable,magnesium bodies,soft-touch controls.
»Press the“AFS”(Auto Frequency Selection)button 3S, the receiver will auto-scan and lock on to an open,interference-free
frequency.
»Press[IR]button to upload automatically the receiver frequency to the transmitter.
» PLL(Phase Lock Loop frequency control) design ensures transmission reliability,“Noise Lock”squelch effectively blocks stray RF.
» EIA-standard metal 1-rack receiver chassis,offering programmable features,with high-visibility LCD display.
» Battery life is twice as common,up to 15 hours.
» Provide incredible audio quality, outstandingly reliable performance for artists, broad-casters, other demanding audio environments.
Receiver |
|
Main Frame Size | EIA STANDARD 1 U |
Channels | Dual Channel |
Frequency Stability | ±0.0005%,Phase Lock Loop frequency control |
Carrier Frequency Range | UHF 740-820MHz |
Modulation Mode | FM |
Operating Range | 100M typical (in open space) |
Oscillation | PLL synthesized |
Sensitivity | 5dB μV, S/N>60dB at 25 deviation |
Band Width | 40MHz |
S/N |
>108 dB |
T.H.D. |
<0.4% @ 1 KHz |
Integrated frequency response |
65Hz~18kHz ± 3dB |
Power Supply |
100-240V AC50/60Hz,10W |
Weight |
4.3KG |
Wireless Microphone |
|
Carrier Frequency Range |
UHF 740-820MHz |
Oscillation |
PLL synthesized |
Harmonic radiation |
< -63dBm |
Bandwidth |
80MHz |
Max.Deviation Range |
±45KHz |
Microphone Element |
Cardioid Dynamic |
RF Power Output |
RF Power Output: 8mW ; 8mW / 15mW(Selectable) |
Battery |
AA×2 |
Current Consumption |
90 mA |
Battery Current / Life |
Almost 6 Hours |
Dimension(mm) |
265mm(L)×56mm(diameter) |
